Seri
Kapı Erişim Sistemleri
Enterprise WiFi — ubiquiti G3 Starter Kit Pro, Kapı Erişim Sistemleri kategorisinde yer alan profesyonel Ubiquiti Kamera çözümüdür. Door Hub: Supported Doors: 1. Turkey'de proje, deployment ve technical support için Safir Teknoloji.
Ubiquiti G3 Starter Kit Pro — network device, Ubiquiti Kamera portföyünde kurumsal ve ticari projeler için konumlanır. Kapı Erişim Sistemleri kategorisindeki altyapı ihtiyaçlarına yöneliktir.
Kurumsal projelerde keşif, tedarik ve teknik destek için Safir Teknoloji yetkili çözüm ortağıdır.
Ethernet Portları: (5) 10/100/1000 Base-T
Kapı Erişim Sistemleri
30W (Without PoE output) 50W (With PoE output)
Merkezi kayıt ve uzaktan izleme entegrasyonu.
Düşük ışıkta net görüntü seçenekleri (modele bağlı).
Proje ihtiyacınıza göre doğru Ubiquiti Kamera önerisi.
Toplu alım, bayi ve kamu ihale süreçlerinde fiyatlandırma desteği.
Saha montajı, yapılandırma ve devreye alma koordinasyonu.
Satış sonrası arıza, firmware ve topoloji danışmanlığı.
İlgili ürün grubu: Kapı Erişim Sistemleri
Ubiquiti G3 Starter Kit Pro — network device hakkında en çok sorulan konular — proje planlama, teknik özellikler ve satış süreçleri.
UniFi access point sistemleri hotel WiFi, kampüs ağı, AVM, plaza ve kurumsal ofislerde enterprise WiFi çözümleri için tercih edilir. Kullanıcı yoğunluğu ve tavan yüksekliğine göre U6/U7 modelleri önerilir; ürün kataloğu üzerinden serileri inceleyebilirsiniz.
Dream Machine ve UCG serisi gateway; routing, firewall, CODE1 ve UniFi Network yönetimini tek cihazda birleştirir. Enterprise network projelerinde omurga cihazı olarak konumlanır.
UniFi OS konsolu, yerel Network Application veya UniFi Cloud ile access point, switch ve Protect kameralar tek panelden izlenir. Merkezi yönetim ile firmware ve VLAN policy dağıtımı yapılır.
WiFi 7 modelleri yüksek yoğunluk ve düşük gecikme gerektiren etkinlik alanlarında; WiFi 6 geniş kurumsal kapsama için ekonomik ölçek sunar. Kanal genişliği ve CODE1 kapasitesi modele göre değişir.
UniFi Protect CODE1 ve G5 kamera ailesi aynı ekosistemde PoE switch üzerinden kurulur. IP camera sistemleri ile gateway VLAN ayrımı planlanmalıdır.
access point ve kamera sayısına göre PoE++ bütçesi ve port yoğunluğu hesaplanır. Pro Max ve Enterprise switch serileri yedekli omurga için uygundur.
UISP saha ve ISP tarafı wireless backhaul yönetimi içindir; UniFi kurumsal CODE1 ve güvenlik katmanıdır. Karma projelerde her iki panel ayrı rol oynar.
Misafir ve personel ağları ayrı CODE1 ile tasarlanır; captive portal ihtiyacında gateway üzerinde hotspot veya harici controller entegre edilir. hotel WiFi sistemi için site survey şarttır.
AP yerleşimi, minimum RSSI ve fast roaming ayarları controller üzerinden yapılır. Kampüs ağı projelerinde fiber omurga + PoE access point kombinasyonu yaygındır.
Orta ölçekli ofis projelerinde birkaç gün; çok bina kampüslerinde haftalar sürebilir. Keşif, kablolama ve devreye alma aşamaları ayrı planlanır.
Güncel UniFi Network, Protect ve mobil uygulama paketleri indirme merkezi sayfasında listelenir. Üretim ortamında upgrade öncesi yedek alınmalıdır.
Misafir interneti hotspot çözümleri gateway veya harici router ile kurulur; 5651 loglama Safir Cloud entegrasyonu ile merkezi arşivlenir.
Yüksek tavan ve metal rack ortamlarında directional AP veya mesh planı yapılır. Fabrika ağı segmentasyonu için VLAN ve QoS tanımlanır.
Model listesi ve adet bilgisiyle kurumsal teklif hazırlanır; proje takvimine göre stok koordinasyonu yapılır. teklif formu üzerinden iletebilirsiniz.
Tasarım, VLAN, controller deploymentu, AP montajı ve arıza analizi satış sonrası destek kapsamındadır. Enterprise network projelerinde uzaktan ve saha desteği sunulur.
UniFi OS sürüm matrisi ve cihaz generation bilgisi indirme merkezi ve teknik dokümanlardan kontrol edilir. Karma nesil projelerde danışmanlık önerilir.
Cihaz başına kapasite ve kanal planı site survey ile çıkarılır. enterprise WiFi çözümleri için minimum -65 dBm hedeflenir.
Açık alan, otopark ve saha WiFi için IP67 outdoor AP modelleri kullanılır; fiber veya wireless backhaul ile omurgaya bağlanır.
Ubiquiti G3 Starter Kit Pro — network device Ubiquiti teknik özellikleri aşağıdaki tabloda özetlenmiştir. Kurumsal network altyapısı ve profesyonel ağ çözümü projelerinde Kamera sınıfı ürünler için datasheet ve üretici kaynakları referans alınmıştır.
| Teknik Alan | Değer |
|---|---|
| Marka | Ubiquiti |
| Model | UA-G3-SK-Pro |
| Ürün Tipi | Kamera |
| Seri | Kapı Erişim Sistemleri |
| Çözünürlük | 30W (Without PoE output) 50W (With PoE output) |
| Gece Görüşü / IR | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| PoE Desteği | (1) PoE++ input, 50V DC, 1A (4) PoE outputs, 50V DC, 30W per port (Max 45W aggregated) |
| Ethernet Portları | (5) 10/100/1000 Base-T |
| Çalışma Sıcaklığı | 0 to 40° C (32 to 104° F) |
| Boyutlar | 174.9 x 126 x 32.9 mm (6.9 x 5 x 1.3") |
| Montaj Tipi | Polycarbonate |
| Outdoor / IP Koruma | Kamera |
| Sertifikalar | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| Üretici Sayfası | Belirtilmemiş |
| Datasheet Kaynağı | Belirtilmemiş |
| In the Box | (1) Door Hub (1) G3 Reader Pro (1) G3 Reader (2) Pocket Keyfobs — G3 Reader for door exit, or entry for an additional door (second Hub required) |
| Touch Pass | 10 free 1-year Touch Passes included <a href="https://help.ui.com/hc/en-us/articles/27130425853079-UniFi-Access-Touch-Pass-Configuration" target="_blank" rel="noopener noreferrer">Detaylı Bilgi</a> |
| Door Hub: Dimensions | 174.9 x 126 x 32.9 mm (6.9 x 5 x 1.3") |
| Door Hub: Supported Doors | 1 |
| Door Hub: Maximum User Count | 6,000 |
| Door Hub: Input Terminals | (2) Door exit request (1) Door position (1) Emergency |
| Door Hub: Power Method | PoE++ UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| Door Hub: Weight | 363 g (12.8 oz) |
| Door Hub: Enclosure Material | Polycarbonate |
| Door Hub: Mount Material | Polycarbonate |
| Door Hub: Mounting | DIN-rail (Included) |
| Door Hub: Networking Interface | (5) 10/100/1000 Base-T |
| Door Hub: PoE Interface | (1) PoE++ input, 50V DC, 1A (4) PoE outputs, 50V DC, 30W per port (Max 45W aggregated) |
| Door Hub: Max. Power Consumption | 30W (Without PoE output) 50W (With PoE output) |
| Door Hub: Digital Input | Request to exit, request to enter, remote release, door position sensor |
| Door Hub: Dry Output Relay | Lock: 30V DC, 1A Aux: 30V DC, 1A |
| Door Hub: Powered Output Relay | Lock: 12V DC, 1A Aux: 12V DC, 0.33A 12V DC, 0.33A |
| Door Hub: LEDs | B/W <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Detaylı Bilgi</a> |
| Door Hub: Button | (1) Factory reset |
| Door Hub: UA-Lock-Electric (400mA) | 24 AWG length: 25 m (82 ft) 22 AWG length: 42 m (138 ft) 20 AWG length: 66 m (217 ft) 18 UACC-Cable-DoorLockRelay length: 100 m (328 ft) |
| Door Hub: UA-Lock-Magnetic-540kg (500mA) | 24 AWG length: 20 m (66 ft) 22 AWG length: 32 m (105 ft) 20 AWG length: 51 m (167 ft) 18 UACC-Cable-DoorLockRelay length: 80 m (262 ft) |
| Door Hub: UA-Lock-Magnetic-270kg (800mA) | 24 AWG length: 12 m (39 ft) 22 AWG length: 20 m (66 ft) 20 AWG length: 30 m (98 ft) 18 UACC-Cable-DoorLockRelay length: 46 m (151 ft) |
| Door Hub: Other locks (1A) | 24 AWG length: 9 m (30 ft) 22 AWG length: 15 m (49 ft) 20 AWG length: 24 m (79 ft) 18 UACC-Cable-DoorLockRelay length: 36 m (118 ft) |
| Door Hub: PoE Cabling Requirements | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| Door Hub: UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Door Hub: UL 294 Statement | Compliance with IEEE 802.3 (at or af) specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| Door Hub: CAN/ULC-60839-11-1 Grade | Grade assignment: 1 |
| Door Hub: Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Door Hub: Ambient Operating Humidity | 5 to 95% noncondensing |
| Door Hub: Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Door Hub: Management Application | UniFi Access |
| Door Hub: Software Information | The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a> |
| Door Hub: Document number, and issue date and/or revision level | UA-Hub-Door002, V01 |
| G3 Reader Pro: Dimensions | 160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6") |
| G3 Reader Pro: Integrated Kamera | View angle: H: 96.67°, V: 123.15°, D: 153.11° |
| G3 Reader Pro: Weatherproofing | IP55 |
| G3 Reader Pro: Weight | 136 g (4.8 oz) |
| G3 Reader Pro: Enclosure Material | Polycarbonate, glass |
| G3 Reader Pro: Mount Material | Aluminum alloy |
| G3 Reader Pro: Mounting | Wall, gang-box mount (Included) Angle mount, junction box (Optional) |
| G3 Reader Pro: Networking Interface | (1) GbE RJ45 port |
| G3 Reader Pro: Connectivity | BLE 4.2 NFC |
| G3 Reader Pro: Power Method | PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| G3 Reader Pro: Max. Power Consumption | 6W |
| G3 Reader Pro: Supported Voltage Range | 48V DC |
| G3 Reader Pro: ESD/EMP Protection | Air: ±15kV, contact: ±8kV |
| G3 Reader Pro: Max. Frame Rate | 30 FPS |
| G3 Reader Pro: Resolution | 1280 x 286 px |
| G3 Reader Pro: Field of View | H: 98.6°, V: 125.7°, D: 157.8° |
| G3 Reader Pro: Sensors | Proximity sensor |
| G3 Reader Pro: Size | 120 mm (4.7") diagonal |
| G3 Reader Pro: Screen Technology | Capacitive touch |
| G3 Reader Pro: Luminance | 480 nits (Typical) |
| G3 Reader Pro: Screen Orientation | Portrait |
| G3 Reader Pro: Speaker | (1) Yes, 1.5W |
| G3 Reader Pro: LEDs | R/G/B/W/Amber <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Detaylı Bilgi</a> |
| G3 Reader Pro: Button | (1) Factory reset |
| G3 Reader Pro: NFC Frequency | 13.56 MHz |
| G3 Reader Pro: NFC Read Range | < 30 mm (1.18'') |
| G3 Reader Pro: NFC Technology | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0 |
| G3 Reader Pro: PoE Cabling Requirements | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| G3 Reader Pro: Ambient Operating Humidity | 5 to 90% noncondensing |
| G3 Reader Pro: UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| G3 Reader Pro: UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| G3 Reader Pro: CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| G3 Reader Pro: Ambient Operating Temperature | Device: -30 to 45° C (-22 to 113° F) Display: -10 to 45° C (14 to 113° F) — The display will turn off when the ambient temperature is above/below the display operation temperature, but other functions will remain functional. |
| G3 Reader Pro: Certifications | CE, FCC, IC,UL 294, CAN/ULC-60839-11-1 |
| G3 Reader Pro: Document number, and issue date and/or revision level | UA-G3-Pro-W/UA-G3-Pro-B, V01 |
| G3 Reader Pro: Management Application | UniFi Access |
| G3 Reader Pro: Software Information | The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a> |
| G3 Reader: Dimensions | 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4") |
| G3 Reader: Weatherproofing | IP55 |
| G3 Reader: Weight | 82 g (2.9 oz) |
| G3 Reader: Enclosure Material | Polycarbonate, glass |
| G3 Reader: Mount Material | Aluminum alloy |
| G3 Reader: Mounting | In-wall, gang box (Included) Junction box (Optional) |
| G3 Reader: Networking Interface | (1) 10/100 MbE RJ45 port |
| G3 Reader: Connectivity | BLE 4.1 NFC |
| G3 Reader: Power Method | PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| G3 Reader: Max. Power Consumption | 5W |
| G3 Reader: Supported Voltage Range | 48V DC |
| G3 Reader: ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV |
| G3 Reader: Sensors | Proximity sensor |
| G3 Reader: Speaker | (1) Yes, 0.7W |
| G3 Reader: LEDs | R/G/B/W <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Detaylı Bilgi</a> |
| G3 Reader: Button | (1) Factory reset |
| G3 Reader: NFC Frequency | 13.56 MHz |
| G3 Reader: NFC Read Range | < 30 mm (1.18'') |
| G3 Reader: NFC Technology | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0 |
| G3 Reader: PoE Cabling Requirements | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| G3 Reader: UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| G3 Reader: UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| G3 Reader: CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| G3 Reader: Ambient Operating Temperature | -30 to 45° C (-22 to 113° F) |
| G3 Reader: Ambient Operating Humidity | 5 to 90% noncondensing |
| G3 Reader: Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| G3 Reader: Document number, and issue date and/or revision level | UA-G3, V01 |
| G3 Reader: Management Application | UniFi Access |
| G3 Reader: Software Information | The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a> |
| Pocket Keyfob: Dimensions | 84 x 39 x 7.4 mm (3.3 x 1.5 x 0.29") |
| Pocket Keyfob: Weight | 16 g (0.56 oz) |
| Pocket Keyfob: Enclosure Material | Polycarbonate, stainless steel, silicone rubber |
| Pocket Keyfob: Weatherproofing | IP54 |
| Pocket Keyfob: Ambient Operating Humidity | 10 to 90% noncondensing |
| Pocket Keyfob: Ambient Operating Temperature | -10 to 45° C (14 to 113° F) |
| Pocket Keyfob: NFC Frequency | 13.56 MHz |
| Pocket Keyfob: NFC Technology | ISO/IEC 14443 Type A MIFARE DESFire EV3 4K UniFi Access Proprietary Security Protocol |
| Pocket Keyfob: Certification | CE |
